Chain load turning device is a mechanical device mainly used for turning and moving heavy objects, and realizes the turning and conveying functions of objects through chain transmission. This equipment is efficient, durable, flexible and widely used in many industries. Chain load turning device is mainly composed of driving device, transmission device, turning device and support frame. The driving device provides power, the transmission device transmits the power to the flipping device, the flipping device realizes the flipping and transmission of the chain plate, and the supporting frame plays the role of supporting and fixing other parts.
The working principle of the chain load turning device is to drive the transmission shaft through the motor to connect the flip plate with the sprocket, thereby driving the chain plate to flip. At the same time, the drive shaft also transmits power to the chain on the support frame, allowing the chain to achieve continuous transportation. This kind of equipment can flexibly adjust the turning angle to adapt to different material characteristics and process requirements. It has a 360° rotation function for objects and can be turned to any angle as required. It is simple to operate, flexible and reliable to use.
Application of chain load turning device in foundries
Sand box flipping
Chain load turning device is often used for turning over and closing sand boxes in foundry workshops. This kind of equipment can complete the flipping of the sand box efficiently and stably, improve production efficiency, and reduce the difficulty and danger of manual operation.
Workpiece handling
Chain load turning device can also be used for turning over large and heavy workpieces during machining, as well as for inclined spraying of flow-coating sand boxes. These applications demonstrate the versatility and efficiency of chain load turning devices in foundries.
Automated processing of sand cores and cores
In the production of complex castings, the placement and removal of sand cores and mold cores are important links. Chain load turning device can customize different shapes of flip frames according to needs to adapt to sand cores and mold cores of different sizes and shapes. Through programming control, the turning machine can automatically complete operations such as placing, turning and removing sand cores and mold cores, improving the automation of the production line and ensuring the accuracy and quality of castings.
Assistance with cleaning and inspection processes
Castings are turned over for easier cleaning and inspection. Chain load turning device can be used in conjunction with cleaning equipment such as sandblasting machines and shot blasting machines to achieve automated cleaning of castings. At the same time, the precise control function of the turning machine enables castings to present the best inspection angle, allowing quality inspection personnel to quickly and accurately find defects, improving the efficiency and accuracy of product quality inspection.
Production line integration and automation upgrade
With the development of intelligent manufacturing, foundries are gradually transforming and upgrading towards automation and intelligence. As one of the important equipment on the production line, the chain load turning device can be easily integrated into the existing automation system to achieve seamless docking and collaborative work with other equipment. Through the integrated control system, the turning machine can be remotely monitored and intelligently scheduled, further improving the overall efficiency and flexibility of the production line.
